Feather_M0_LoRa.ino

// Include necessary libraries
#include
#include
#include <avr/pgmspace.h>
#include
#include <hal/hal.h>
#include
#include "dtostrf.h"

/**
* How often should data be sent?
*/
#define UpdateInterval 30 // Update Every 30 mins

/**
* Startup message to send
*/
#define STARTUP_MESSAGE "Hello World!"

/**
* Sensors to enable
* Uncomment the sensors you want to use
*/
#define SENSOR_FEATHER_BATTERY // Battery Voltage
#define SENSOR_FEATHER_MEMORY // Free memory
//#define SENSOR_DHT11 // DHT 11
//#define SENSOR_DHT21 // DHT 21 (AM2301)
//#define SENSOR_DHT22 // DHT 22 (AM2302)
//#define SENSOR_BMP085 // BMP085
//#define SENSOR_BMP180 // BMP180
//#define SENSOR_BMP280 // BMP280
//#define SENSOR_BME280 // BME280
//#define SENSOR_TSL2561 // TLS2561
//#define SENSOR_BH1750 // BH1750FVI
//#define SENSOR_DS18B20 // DS18B20
//#define SENSOR_SR04PLUS // HC-SR04+

// LoRaWAN Config
// Device Address
devaddr_t DevAddr = 0x00000000;

// Network Session Key
unsigned char NwkSkey[16] = { 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00 };

// Application Session Key
unsigned char AppSkey[16] = { 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00 };


/*****
* --- Nothing needs to be changed below here ---
*****/
// Feather M0 RFM9x pin mappings
lmic_pinmap pins = {
.nss = 8, // Internal connected
.rxen = 0, // Not used for RFM92/RFM95
.txen = 0, // Not used for RFM92/RFM95
.rst = 4, // Internal connected
.dio = {3, 5, 6}, // Connect "i01" to "5"
// Connect "D2" to "6"
};

// Track if the current message has finished sending
bool dataSent = false;

/**
* DHT Humidity/Temperature sensor
*/
#if defined(SENSOR_DHT11) || defined(SENSOR_DHT22) || defined(SENSOR_DHT21)
#include
#include
#include
#endif

#if defined(SENSOR_DHT11)
DHT_Unified dht(9, DHT11);
#elif defined(SENSOR_DHT21)
DHT_Unified dht(9, DHT21);
#elif defined(SENSOR_DHT22)
DHT_Unified dht(9, DHT22);
#endif


/**
* BMP085/BMP180
*/
#if defined(SENSOR_BMP085) || defined(SENSOR_BMP180)
#include
#include
#include
Adafruit_BMP085_Unified bmp = Adafruit_BMP085_Unified(10085);
#endif
#if defined(SENSOR_BMP280)
#include
Adafruit_BMP280 bmp280;
#endif
#if defined(SENSOR_BME280)
#include
Adafruit_BME280 bme280;
#endif

/**
* TLS2561
*/
#if defined(SENSOR_TSL2561)
#include
#include
#include
Adafruit_TSL2561_Unified tsl = Adafruit_TSL2561_Unified(TSL2561_ADDR_FLOAT, 12345);
#endif

/**
* BH1750
*/
#if defined(SENSOR_BH1750)
#include
#define _delay_ms(ms) delayMicroseconds((ms) * 1000)
#include
BH1750 bh1750;
#endif

/**
* DS18B20 temperature sensor
*/
#if defined(SENSOR_DS18B20)
#include
#include
#endif

/**
* HC-SR04+ ultrasonic distance sensor
*/
#if defined(SENSOR_SR04PLUS)
#include
#define TRIGGER_PIN 12 // pin tied to trigger pin on the ultrasonic sensor.
#define ECHO_PIN 11 // pin tied to echo pin on the ultrasonic sensor.
#define MAX_DISTANCE 200 // Maximum distance we want to ping for (in centimeters). Maximum sensor distance is rated at 400-500cm.
NewPing sonar(TRIGGER_PIN, ECHO_PIN, MAX_DISTANCE); // NewPing setup of pins and maximum distance.
#endif

/**
* Device Start Up
*/
void setup() {
// Startup delay for Serial interface to be ready
Serial.begin(115200);
delay(3000);

// Debug message
Serial.println("Starting...");

// Some sensors require a delay on startup
elapsedMillis sinceStart = 0;
int sensorReady = 0;

#if defined(SENSOR_DHT11) || defined(SENSOR_DHT22) || defined(SENSOR_DHT21)
// Initialize the DHT sensor.
dht.begin();
sensor_t sensor;
dht.temperature().getSensor(&sensor);
dht.humidity().getSensor(&sensor);
sensorReady = max(sensorReady, (sensor.min_delay / 1000) + sinceStart);
#endif

#if defined(SENSOR_BMP085) || defined(SENSOR_BMP180)
// Initialize the BMP pressure sensor
bmp.begin();
#endif
#if defined(SENSOR_BMP280)
// Initialize the BMP280 pressure sensor
bmp280.begin();
#endif
#if defined(SENSOR_BME280)
// Initialize the BME280 pressure sensor
bme280.begin();
#endif

#if defined(SENSOR_TSL2561)
// Initialize the TSL2561 Digital Luminosity sensor
tsl.begin();
tsl.enableAutoRange(true);
tsl.setIntegrationTime(TSL2561_INTEGRATIONTIME_101MS);
#endif

#if defined(SENSOR_BH1750)
bh1750.begin(BH1750_CONTINUOUS_HIGH_RES_MODE_2);
sensorReady = max(sensorReady, 1000 + sinceStart);
#endif

// Setup LoRaWAN state
initLoRaWAN();

// Wait for all the sensors to be ready
if (sensorReady > sinceStart) {
// A sensor still needs some time
delay(max(0, (int)(sensorReady - sinceStart)));
}

#if defined(STARTUP_MESSAGE)
// Send Startup Message
sendStartupMessage();
delay(1000);
#endif

// Shutdown the radio
os_radio(RADIO_RST);

// Debug message
Serial.println("Startup Complete");
}

void initLoRaWAN() {
// LMIC init
os_init();

// Reset the MAC state. Session and pending data transfers will be discarded.
LMIC_reset();

// by joining the network, precomputed session parameters are be provided.
LMIC_setSession(0x1, DevAddr, (uint8_t*)NwkSkey, (uint8_t*)AppSkey);

// Enabled data rate adaptation
LMIC_setAdrMode(1);

// Enable link check validation
LMIC_setLinkCheckMode(0);

// Set data rate and transmit power
LMIC_setDrTxpow(DR_SF12, 21);
}

void loop() {
// Start timing how long since starting to send data
elapsedMillis sinceWake = 0;

// Debug message
Serial.println("\nBeginning to send data");

// Send Battery Voltage
#if defined(SENSOR_FEATHER_BATTERY)
sendBattery();
delay(1000);
#endif

// Send Free Memory
#if defined(SENSOR_FEATHER_MEMORY)
sendFreeMemory();
delay(1000);
#endif

// Send DHT
#if defined(SENSOR_DHT11) || defined(SENSOR_DHT22) || defined(SENSOR_DHT21)
sendDHT();
delay(1000);
#endif

// Send Barmometric Pressure
#if defined(SENSOR_BMP085) || defined(SENSOR_BMP180)
sendBMP();
delay(1000);
#endif
#if defined(SENSOR_BMP280)
sendBMP280();
delay(1000);
#endif
#if defined(SENSOR_BME280)
sendBME280();
delay(1000);
#endif

// Send Light Intensity
#if defined(SENSOR_TSL2561) || defined(SENSOR_BH1750)
sendLux();
delay(1000);
#endif

// Send Temperature
#if defined(SENSOR_DS18B20)
sendTemperature();
delay(1000);
#endif

// Send Distance in centimeters
#if defined(SENSOR_SR04PLUS)
sendDistance();
delay(1000);
#endif

// Shutdown the radio
os_radio(RADIO_RST);

// Output sleep time
int sleepSeconds = 60 * UpdateInterval;
sleepSeconds -= sinceWake/1000;
Serial.print("Sleeping for ");
Serial.print(sleepSeconds);
Serial.println(" seconds");
delay(500); // time for Serial send buffer to clear

// Actually go to sleep
signed long sleep = 60000 * UpdateInterval;
sleep -= sinceWake;
delay(constrain(sleep, 10000, 60000 * UpdateInterval));
}

/**
* Send a message with the distance
*/
#if defined(SENSOR_SR04PLUS)
void sendDistance() {
// Ensure there is not a current TX/RX job running
if (LMIC.opmode & (1 << 7)) {
// Something already in the queque
return;
}

// Get the distance
char packet[40] = "";
strcat(packet, "Distance: ");
strcat(packet, sonar.ping_cm());


// Debug message
Serial.print(" seqno ");
Serial.print(LMIC.seqnoUp);
Serial.print(": ");
Serial.println(packet);

// Add to the queque
dataSent = false;
uint8_t lmic_packet[40];
strcpy((char *)lmic_packet, packet);
LMIC_setTxData2(1, lmic_packet, strlen((char *)lmic_packet), 0);

// Wait for the data to send or timeout after 15s
elapsedMillis sinceSend = 0;
while (!dataSent && sinceSend < 15000) {
os_runloop_once();
delay(1);
}
os_runloop_once();
}
#endif

/**
* Send a message with the light intensity
*/
#if defined(SENSOR_TSL2561) || defined(SENSOR_BH1750)
void sendLux() {
// Ensure there is not a current TX/RX job running
if (LMIC.opmode & (1 << 7)) {
// Something already in the queque
return;
}

// Put together the data to send
char packet[40] = "";

#if defined(SENSOR_TSL2561)
// Get sensor event and print its value.
sensors_event_t event;
tsl.getEvent(&event);
if (event.light) {
char floatStr[10];
dtostrf(event.light, 3, 2, floatStr);
strcat(packet, "Light: ");
strcat(packet, floatStr);
#if defined(SENSOR_BH1750)
strcat(packet, " lux\n");
#else
strcat(packet, " lux");
#endif
} else {
Serial.println("Error reading light intensity!");
}
#endif

#if defined(SENSOR_BH1750)
// Get the BH1750 value
uint16_t lux = bh1750.readLightLevel();
char floatStr[10];
dtostrf((float)lux, 3, 2, floatStr);
strcat(packet, "Light: ");
strcat(packet, floatStr);
strcat(packet, " lux");
#endif

if (!strlen(packet)) {
// Don't send empty packet
return;
}

// Debug message
Serial.print(" seqno ");
Serial.print(LMIC.seqnoUp);
Serial.print(": ");
Serial.println(packet);

// Add to the queque
dataSent = false;
uint8_t lmic_packet[40];
strcpy((char *)lmic_packet, packet);
LMIC_setTxData2(1, lmic_packet, strlen((char *)lmic_packet), 0);

// Wait for the data to send or timeout after 15s
elapsedMillis sinceSend = 0;
while (!dataSent && sinceSend < 15000) {
os_runloop_once();
delay(1);
}
os_runloop_once();
}
#endif

/**
* Send a message with the temperature
*/
#if defined(SENSOR_DS18B20)
void sendTemperature() {
// Ensure there is not a current TX/RX job running
if (LMIC.opmode & (1 << 7)) {
// Something already in the queque
return;
}

// Put together the data to send
char packet[40] = "Temperature: ";

// Setup the one wire connection on pin 10
OneWire oneWire(10);
DallasTemperature sensors(&oneWire);
DeviceAddress thermometer;

// Get the temp
sensors.begin();
sensors.getAddress(thermometer, 0);
sensors.setResolution(thermometer, 12);
sensors.requestTemperatures();
float temp = sensors.getTempC(thermometer);
char floatStr[10];
dtostrf(temp, 3, 2, floatStr);
strcat(packet, floatStr);
strcat(packet, "*C");

// Debug message
Serial.print(" seqno ");
Serial.print(LMIC.seqnoUp);
Serial.print(": ");
Serial.println(packet);

// Add to the queque
dataSent = false;
uint8_t lmic_packet[40];
strcpy((char *)lmic_packet, packet);
LMIC_setTxData2(1, lmic_packet, strlen((char *)lmic_packet), 0);

// Wait for the data to send or timeout after 15s
elapsedMillis sinceSend = 0;
while (!dataSent && sinceSend < 15000) {
os_runloop_once();
delay(1);
}
os_runloop_once();
}
#endif

/**
* Send a message with the temperature and pressure
*/
#if defined(SENSOR_BMP085) || defined(SENSOR_BMP180)
void sendBMP() {
// Ensure there is not a current TX/RX job running
if (LMIC.opmode & (1 << 7)) {
// Something already in the queque
return;
}

// Put together the data to send
char packet[40] = "";

// Get temperature event and print its value.
float temperature;
sensors_event_t event;
bmp.getEvent(&event);
bmp.getTemperature(&temperature);
if (temperature) {
char floatStr[10];
dtostrf(temperature, 3, 2, floatStr);
strcat(packet, "Temp: ");
strcat(packet, floatStr);
strcat(packet, "*C\n");
} else {
Serial.println("Error reading temperature!");
}

// Get pressure event and print its value.
if (event.pressure) {
char floatStr[10];
dtostrf(event.pressure, 3, 2, floatStr);
strcat(packet, "Pressure: ");
strcat(packet, floatStr);
strcat(packet, "hPa");
} else {
Serial.println("Error reading pressure!");
}

if (!strlen(packet)) {
// Don't send empty packet
return;
}

// Debug message
Serial.print(" seqno ");
Serial.print(LMIC.seqnoUp);
Serial.print(": ");
Serial.println(packet);

// Add to the queque
dataSent = false;
uint8_t lmic_packet[40];
strcpy((char *)lmic_packet, packet);
LMIC_setTxData2(1, lmic_packet, strlen((char *)lmic_packet), 0);

// Wait for the data to send or timeout after 15s
elapsedMillis sinceSend = 0;
while (!dataSent && sinceSend < 15000) {
os_runloop_once();
delay(1);
}
os_runloop_once();
}
#endif
#if defined(SENSOR_BMP280)
void sendBMP280() {
// Ensure there is not a current TX/RX job running
if (LMIC.opmode & (1 << 7)) {
// Something already in the queque
return;
}

// Put together the data to send
char packet[40] = "";

// Get temperature event and print its value.
float temperature = bmp280.readTemperature();
if (temperature) {
char floatStr[10];
dtostrf(temperature, 3, 2, floatStr);
strcat(packet, "Temp: ");
strcat(packet, floatStr);
strcat(packet, "*C\n");
} else {
Serial.println("Error reading temperature!");
}

// Get pressure event and print its value.
float pressure = bmp280.readPressure() / 100.0F;
if (pressure) {
char floatStr[10];
dtostrf(pressure, 3, 2, floatStr);
strcat(packet, "Pressure: ");
strcat(packet, floatStr);
strcat(packet, "hPa");
} else {
Serial.println("Error reading pressure!");
}

if (!strlen(packet)) {
// Don't send empty packet
return;
}

// Debug message
Serial.print(" seqno ");
Serial.print(LMIC.seqnoUp);
Serial.print(": ");
Serial.println(packet);
// Add to the queque
dataSent = false;
uint8_t lmic_packet[40];
strcpy((char *)lmic_packet, packet);
LMIC_setTxData2(1, lmic_packet, strlen((char *)lmic_packet), 0);

// Wait for the data to send or timeout after 15s
elapsedMillis sinceSend = 0;
while (!dataSent && sinceSend < 15000) {
os_runloop_once();
delay(1);
}
os_runloop_once();
}
#endif
#if defined(SENSOR_BME280)
void sendBME280() {
// Ensure there is not a current TX/RX job running
if (LMIC.opmode & (1 << 7)) {
// Something already in the queque
return;
}

// Put together the data to send
char packet[40] = "";

// Get temperature event and print its value.
float temperature = bme280.readTemperature();
if (temperature) {
char floatStr[10];
dtostrf(temperature, 3, 2, floatStr);
strcat(packet, "Temp: ");
strcat(packet, floatStr);
strcat(packet, "*C\n");
} else {
Serial.println("Error reading temperature!");
}

// Get pressure event and print its value.
float pressure = bme280.readPressure() / 100.0F;
if (pressure) {
char floatStr[10];
dtostrf(pressure, 3, 2, floatStr);
strcat(packet, "Pressure: ");
strcat(packet, floatStr);
strcat(packet, "hPa\n");
} else {
Serial.println("Error reading pressure!");
}

// Get humidity and print its value.
float humidity = bme280.readHumidity();
if (humidity) {
char floatStr[10];
dtostrf(pressure, 3, 2, floatStr);
strcat(packet, "Humidity: ");
strcat(packet, floatStr);
strcat(packet, "%");
} else {
Serial.println("Error reading humidity!");
}

if (!strlen(packet)) {
// Don't send empty packet
return;
}

// Debug message
Serial.print(" seqno ");
Serial.print(LMIC.seqnoUp);
Serial.print(": ");
Serial.println(packet);
// Add to the queque
dataSent = false;
uint8_t lmic_packet[40];
strcpy((char *)lmic_packet, packet);
LMIC_setTxData2(1, lmic_packet, strlen((char *)lmic_packet), 0);

// Wait for the data to send or timeout after 15s
elapsedMillis sinceSend = 0;
while (!dataSent && sinceSend < 15000) {
os_runloop_once();
delay(1);
}
os_runloop_once();
}
#endif

/**
* Send a message with the temperature and humidity
*/
#if defined(SENSOR_DHT11) || defined(SENSOR_DHT22) || defined(SENSOR_DHT21)
void sendDHT() {
// Ensure there is not a current TX/RX job running
if (LMIC.opmode & (1 << 7)) {
// Something already in the queque
return;
}

// Put together the data to send
char packet[30] = "";

// Get temperature event and print its value.
sensors_event_t event;
dht.temperature().getEvent(&event);
if (!isnan(event.temperature)) {
char floatStr[10];
dtostrf(event.temperature, 3, 2, floatStr);
strcat(packet, "Temp: ");
strcat(packet, floatStr);
strcat(packet, "*C\n");
} else {
Serial.println("Error reading temperature!");
}

// Get humidity event and print its value.
dht.humidity().getEvent(&event);
if (!isnan(event.relative_humidity)) {
char floatStr[10];
dtostrf(event.relative_humidity, 3, 2, floatStr);
strcat(packet, "Humidity: ");
strcat(packet, floatStr);
strcat(packet, "%");
} else {
Serial.println("Error reading humidity!");
}

if (!strlen(packet)) {
// Don't send empty packet
return;
}

// Debug message
Serial.print(" seqno ");
Serial.print(LMIC.seqnoUp);
Serial.print(": ");
Serial.println(packet);

// Add to the queque
dataSent = false;
uint8_t lmic_packet[30];
strcpy((char *)lmic_packet, packet);
LMIC_setTxData2(1, lmic_packet, strlen((char *)lmic_packet), 0);

// Wait for the data to send or timeout after 15s
elapsedMillis sinceSend = 0;
while (!dataSent && sinceSend < 15000) {
os_runloop_once();
delay(1);
}
os_runloop_once();
}
#endif

/**
* Send a message with the free memory
*/
#if defined(SENSOR_FEATHER_MEMORY)
extern "C" char *sbrk(int i);
void sendFreeMemory() {
// Ensure there is not a current TX/RX job running
if (LMIC.opmode & (1 << 7)) {
// Something already in the queque
return;
}

// Get the free memory
// https://learn.adafruit.com/adafruit-feather-m0-basic-proto/adapting-sketches-to-m0#how-much-ram-available
char stack_dummy = 0;
int freeMem = &stack_dummy - sbrk(0);

// Convert to a string
char intStr[10];
itoa(freeMem, intStr, 10);

// Put together the data to send
char packet[25] = "Free Memory: ";
strcat(packet, intStr);

// Debug message
Serial.print(" seqno ");
Serial.print(LMIC.seqnoUp);
Serial.print(": ");
Serial.println(packet);

// Add to the queque
dataSent = false;
uint8_t lmic_packet[25];
strcpy((char *)lmic_packet, packet);
LMIC_setTxData2(1, lmic_packet, strlen((char *)lmic_packet), 0);

// Wait for the data to send or timeout after 15s
elapsedMillis sinceSend = 0;
while (!dataSent && sinceSend < 15000) {
os_runloop_once();
delay(1);
}
os_runloop_once();
}
#endif

/**
* Send a message with the battery voltage
*/
#if defined(SENSOR_FEATHER_BATTERY)
void sendBattery() {
// Ensure there is not a current TX/RX job running
if (LMIC.opmode & (1 << 7)) {
// Something already in the queque
return;
}

// Get the battery voltage
float measuredvbat = analogRead(A7); // Hard wired to pin A7 on Adafruit Feather
measuredvbat *= 2; // we divided by 2, so multiply back
measuredvbat *= 3.3; // Multiply by 3.3V, our reference voltage
measuredvbat /= 1024; // convert to voltage

// Convert to a string
char floatStr[10];
dtostrf(measuredvbat, 3, 2, floatStr);

// Put together the data to send
char packet[20] = "Battery: ";
strcat(packet, floatStr);

// Debug message
Serial.print(" seqno ");
Serial.print(LMIC.seqnoUp);
Serial.print(": ");
Serial.println(packet);

// Add to the queque
dataSent = false;
uint8_t lmic_packet[20];
strcpy((char *)lmic_packet, packet);
LMIC_setTxData2(1, lmic_packet, strlen((char *)lmic_packet), 0);

// Wait for the data to send or timeout after 15s
elapsedMillis sinceSend = 0;
while (!dataSent && sinceSend < 15000) {
os_runloop_once();
delay(1);
}
os_runloop_once();
}
#endif

/**
* Send a startup message
*/
#if defined(STARTUP_MESSAGE)
void sendStartupMessage() {
// Ensure there is not a current TX/RX job running
if (LMIC.opmode & (1 << 7)) {
// Something already in the queque
return;
}

// Put together the data to send
char packet[41] = STARTUP_MESSAGE;

// Debug message
Serial.print(" seqno ");
Serial.print(LMIC.seqnoUp);
Serial.print(": ");
Serial.println(packet);

// Add to the queque
dataSent = false;
uint8_t lmic_packet[41];
strcpy((char *)lmic_packet, packet);
LMIC_setTxData2(1, lmic_packet, strlen((char *)lmic_packet), 0);

// Wait for the data to send or timeout after 15s
elapsedMillis sinceSend = 0;
while (!dataSent && sinceSend < 15000) {
os_runloop_once();
delay(1);
}
os_runloop_once();
}
#endif

// ----------------------------------------------------------------------------
// LMIC CALLBACKS
// ----------------------------------------------------------------------------

// LoRaWAN Application identifier (AppEUI)
static const u1_t AppEui[8] PROGMEM = { 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00 };

/**
* Call back to get the AppEUI
*/
void os_getArtEui (u1_t* buf) {
memcpy(buf, AppEui, 8);
}

/**
* Call back to get the Network Session Key
*/
void os_getDevKey (u1_t* buf) {
memcpy(buf, NwkSkey, 16);
}

/**
* Callback after a LMIC event
*/
void onEvent (ev_t ev) {
if (ev == EV_TXCOMPLETE) {
dataSent = true;
}
if (ev == EV_LINK_DEAD) {
initLoRaWAN();
}
}
